• 30.3MP Full-Frame CMOS Sensor
  • Infrared Cut-off Filter for better astrophotography (approx. 4x more sensitivity for Hα wavelength than EOS R)
  • EV -6 focusing limit
  • 5,655 selectable focus positions
  • Up to 30x in-camera live magnification for precise manual focusing
  • Dust and Drip Resistant
Spread the love


EOS Ra (Body)

Stellar Performance

Canon’s first full-frame astrophotography mirrorless interchangeable lens camera with built-in EVF, the EOS Ra features the same RF mount technology as EOS R. Besides being able to Being able to focus in near complete darkness (focus limit of EV -6), the EOS Ra has an IR cut-off filter that is approximately four times more sensitive to Hα wavelength than EOS R, making it perfect for astrophotography. The 5,655 selectable AF positions, made possible with Dual Pixel CMOS AF technology, allows accurate focusing and creative freedom in composition.

The on-board DIGIC 8 processor supports new features such as in-camera Digital Lens Optimiser, and enhances Dual Sensing IS and Combination IS, which provide up to 5 stops Image Stabilization for 30.3-megapixel stills and 4K UHD videos.

The ergonomically designed weather-resistant magnesium alloy body provides reliability. Coupled with Vari-angle touch-screen LCD, the EOS Ra would be your ideal astrophotography companion.

*Silent Shutter available in: Single Shot & Continuous Shot mode.
*Output in 4K(UHD) resolution through processing.



Dual Pixel CMOS AF CG
Dual Pixel Autofocus

Dual Pixel CMOS AF, an autofocus technology in which each effective pixel on the CMOS sensor is able to perform both phase-difference autofocusing and imaging functions. 5,655 selectable AF positions allows greater composition creativity.

​Low-light focusing limit of EV-6 at the central focus point, able to focus even in low-light scenarios where it would be difficult for the human eye.


Capturing Celestial Images

Featuring a specially designed Infrared filter that is based on the original filter in EOS R, EOS Ra is now capable of capturing four times as much transmission of the Hα light (656nm wavelength- hydrogen alpha rays).

This allows for a higher tramsission of deep red infrared rays emitted by nebulae, making EOS Ra ideal for capturing the beauty of the celestial world.


Multifunction Bar
Operability At Its Best

The camera features a multifunction bar on its back, an EOS-series first, that enables both tap and slide operations, allowing for easy changing of shoot settings and image transmission. It also features a built-in 3.96-million-dot high-resolution OLED electronic viewfinder (EVF) with approximately 100% coverage.

Combined with 30x magnification in both the EVF and the Vari-angle touch-screen LCD, EOS Ra ensures precise focus when shooting deep sky imagery.



AF Modes One-Shot AF, Servo AF, Manual
AF Point Selection Automatic selection, Manual selection
AF System Points Max. 5,655 selectable AF point positions / Up to 143 AF areas (auto selection)
Built-in Flash
Closest Focusing Distance (cm)
Continuous Shooting Speed (Shots Per Ssec) (Up To) 8 (One-Shot AF) / 5 (Servo AF)
Dimensions (Excl. Protrusions) (mm) (Approx.) 135.8 x 98.3 x 84.4
Drive System
Effective ISO 100 – 40,000 (L:50, H1:52,100, H1:102,400)
Effective Pixels (Megapixels) 30.3
Exposure Compensation Stills: Manual: ±3 stops in 1/3-stop or 1/2-stop increments, AEB: ±3 stops in 1/3-stop or 1/2-stop increments Movie recording: ±3 stops in 1/3- or 1/2-stop increments
Eye Detection AF Available: One-Shot AF / Servo AF
Flash Modes
Focal Length (35mm Equivalent)
Guide Number ISO 100 metres
Image Resolution 6720 x 4480 (L), 4464 x 2976 (M), 3360 x 2240 (S1), 2400 x 1600 (S2), 6720 x 4480 (RAW), 6720 x 4480 (C-RAW)
Image Stablizer In-body 5-axis electronic image stabilisation
LCD Monitor (Size) (Inch) 3.15
LCD Monitor Resolutions (dots) 2,100,000
Manual Focus Yes
Memory Card Type SD/SDHC/SDXC memory card, UHS-II and UHS-I cards supported
Metering Mode Real-time metering using the image sensor, 384-zone (24×16) metering, Stills: Evaluative, Partial, Spot & Center-weighted average. Video: Center-weighted average and Evaluative metering with the image sensor
Movie Format MP4
Optical Zoom
Optional Power AC Power (Adapter Kit ACK-E6 / USB Power Adapter PD-E1)
Peripheral Connections USB-Type C, HDMI (Type C), Mic-in , headphone, Remote control terminal, WFT-E7 connection
Processor Type DIGIC 8
Sensor Size Full-Frame CMOS
Shooting Modes Stills: Scene Intelligent Auto, Flexible-priority AE, Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure, Bulb exposure, Custom shooting modes (C1/C2/C3) Movies: Scene Intelligent Auto, Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure, Custom shooting modes (C1/C2/C3)
Shutter Speed Range (Sec.) 30 – 1/8000, Bulb
Silent Shutter Available: Single / Continuous Shot
Standard Power Supply Battery Pack LP-E6N / LP-E6
Still Image Format JPEG, RAW, RAW + JPEG, C-RAW, C-RAW+JPEG , RAW(Dual Pixel), C-RAW(Dual Pixel)
Viewfinder Coverage (Approx.) 100%
Viewfinder Type 0.5-inch OLED, 3.69million dots
Weight (g) (Including the battery and memory card) (Approx.)
*For camera kits, weight includes kit lens(es).
White Balance Auto (Ambience priority), Auto (White priority), Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom, Color temperature setting (approx. 2500–10000 K) White balance correction and white balance bracketing features provided * Flash color temperature information transmission possible
X-sync (sec.) 1/200
